Dble Screw Lug(4)1000-500
#4-1000LL4
Double Scrw Lug 4 Aluminum 1000-500
- Large size set-screw connectors with multiple mounting, NEMA spaced holes for a secure, turn-prevent connection
- Made of 6061T-6 aluminum alloy
- Tin plated for low contact resistance
- For use with copper or aluminum conductors
- All hole spacing is NEMA standard of 1.758 inch
Product Information
| Voltage Rating | 600 V |
|---|---|
| Material | 6061T-6 Aluminum Alloy |
| Finish | Tin Plated |
| Pack Qty | 2 |
| GTIN | 662381001788 |
| UPC | 662381001788 |
| EAN | 0662381001788 |
| UNSPSC | 39121466 |
| Ul Standard | UL 486A-486B |
| Conductor Type | Copper, Aluminum |
| Tang Thickness | 0.44 |
| Tang Length | 3.63 |
| Hole Spacing | 1.758 |
| Wire Range | 1000 MCM – 500 MCM |
| Assortment | Aluminum Mechanical Terminations |
Resources
Documents
- POL_AL-CU_MCH_ProdXRef_DIGITAL.pdf Download
